Description: 4-columns car lift with roof PA4R3
The PA4R3 roof-mounted car lift offers the convenience of having a driver on board during lifting. Featuring a 4-column structure and a pit of only 50 cm, it can bear a payload of 2700 kg or, in the XL version, up to 3500 kg. The roof deck can act as a parking surface when the system is in the rest position and can be paved for a maximum weight of 150 kg/m2, maintaining homogeneity with the rest of the yard.
This model integrates advanced safety devices, such as rope control and UPS, and offers options for an upstairs protection fence or a virtual photocell video surveillance and perimeter protection system.
Technical features
- Platform width: 250 - 270 cm
- Platform length: 520 - 560 cm
- Useful capacity: 2700 cm (XL = 3500 cm)
- Pit depth: 50 cm
- Driver present on board during operation
- Customizable roof cover
- Immersive room on request
- High operational and functional safety standards
Integrated car protection against theft - Hot-dip galvanized structure with almond-patterned non-slip sheet metal platform
- Adaptable to different types of contexts: residential units, townhouses, villas, condominiums, renovations, businesses and car dealerships
